Radon Control System Design for Commercial Buildings

A commercial radon control system design is a stamped set of drawings and specifications that tells the builder exactly how to keep radon and other soil gases out of a commercial building, and one is expected for almost every commercial building other than detached one- and two-family houses. The design fixes the sub-slab collection layer, the soil gas barrier, the vent stack routing, and the provision for a fan before the slab is poured, so radon control is built into the structure instead of retrofitted after a failed test.

That is the difference between a few hundred dollars of pipe planned into the pour and a demolition-grade change order later. This page covers what a commercial radon control system has to do, which buildings the design standard covers, what a complete design package contains, how the passive-first sequence works, and how a stamped design clears plan review.

A commercial radon control system does one thing: it collects soil gas from beneath the slab and vents it above the roof before it can enter occupied space. Every part of the design exists to make that collection reliable across a large floor plate.

• A gas-permeable layer, usually clean aggregate, spread under the entire slab so gas can move toward the suction points.
• One or more suction points sized and spaced to the building footprint, because a large commercial slab rarely draws evenly from a single pipe.
• A continuous soil gas barrier over the permeable layer, with every pipe, joint, and utility penetration sealed.
• A vent stack that carries collected gas above the roofline, clear of operable windows and outdoor air intakes.
• A designated fan location and an electrical rough-in beside it, so the system can be powered later without opening finished construction.

The performance target is straightforward. The design has to hold indoor radon below the point where the building needs remediation, which the EPA sets at 4 pCi/L. At or above that level, the building has to be fixed.

Radon control design for commercial construction is governed by ANSI/AARST CC-1000-2018, which sets minimum requirements for soil gas control in new buildings intended for human occupancy other than one- and two-family dwellings. That scope is broad, and it captures the buildings most owners think of as commercial.

• Offices, retail, and other commercial occupancies.
• Educational buildings and childcare facilities.
• Multifamily and congregate residential buildings.
• Mixed-use structures that combine any of the above.

A commercial building differs from a house in ways that change the design, not just the size of it. The slab area is larger, so a single suction point usually will not depressurize the whole footprint. Mechanical ventilation and elevator or stair shafts move air in ways that can pull soil gas upward. Our commercial radon design page covers how those factors shape the suction point count and stack layout for a specific building type.

A design package is the deliverable a plan reviewer, a general contractor, and a lender all read from. A complete one for a commercial building carries every element needed to build and inspect the system without a field guess.

• A sub-slab layout showing suction point locations, count, and spacing across the footprint.
• The gas-permeable layer and soil gas barrier specification, including sealing details at every penetration.
• Vent stack routing and sizing from the suction points to the discharge point above the roof.
• A fan schedule or a designated fan provision, so the system can run active if a test requires it.
• A system monitor or failure indicator that shows an activated fan is working.
• Drawing notes and details that reference the governing standard, so the reviewer can check the design against the code they enforce.

Because the package is stamped, it also carries the design professional's certification that the layout meets the standard, which is what lets the reviewer approve it without redesigning it in the margins.

Almost every commercial building is designed passive first. The full pipe network, permeable layer, and barrier are installed during construction, but no fan runs until a measurement proves one is needed. That sequence keeps the building from paying for continuous fan operation it may never require.

The deciding measurement happens after the building is closed in and tested under occupied conditions. If indoor radon comes back below 4 pCi/L, the passive system stands. If it is at or above that level, a fan is installed to convert the stack to an active system, and the building is retested to confirm the fix. In areas of known high radon potential, the EPA's radon-resistant new construction guidance notes that builders often install a complete active system from the start rather than gamble on passive performance.

The design earns its value by making that conversion a field change. When the fan location, electrical rough-in, monitor, and discharge clearances are already in the permit set, activating the system is mounting a fan and making a connection. When they are missing, the same conversion becomes demolition.

A plan reviewer does not evaluate a radon system on intent. They key a checklist to the governing standard and confirm the drawings meet it line by line. A design that references CC-1000 directly, and shows the sub-slab layout, stack routing, and active-conversion provisions the standard calls for, is a design a reviewer can approve on the first pass instead of returning for corrections.
